Name: Remote Control Hydraulic Rising Bollards , Electric Retractable Bollards Height 600mm
Brand: JC Security Equipment Co., Ltd
SKU: JC052
Availability: InStock

Product Details

Place of Origin: CHINA

Brand Name: SECUSTAR

Certification: CE ISO FCC SGS

Model Number: JC052

Payment & Shipping Terms

Minimum Order Quantity: 1SET

Price: Negotiable

Packaging Details: Wooden Packing

Delivery Time: 7-8 days

Payment Terms: T/T, Western Union, L/C, MoneyGram

Supply Ability: 300 pcs/month

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                automatic retractable parking bollards, automatic pop up bollards


Functions:	Car Parking Bollard	Diameter:	168mm, 219mm, 275mm
Thickness:	6-8mm	Lifting Time:	3-4S
Drive Device:	Hydraulic Or Air Pump	Height:	600mm
Software System:	RFID, Mobile APP, Car License Recognition	Material:	304 Or 316 Stainless Steel Made
Waterproof:	IP68	System Dynamic Power:	350W Integrated

Functions:	Car Parking Bollard
Diameter:	168mm, 219mm, 275mm
Thickness:	6-8mm
Lifting Time:	3-4S
Drive Device:	Hydraulic Or Air Pump
Height:	600mm
Software System:	RFID, Mobile APP, Car License Recognition
Material:	304 Or 316 Stainless Steel Made
Waterproof:	IP68
System Dynamic Power:	350W Integrated

Remote Control Hydraulic Rising Bollards , Electric Retractable Bollards Height 600mm

Security Road barrier Auto Rising Bollards System JC-052

Telescopic bollards are very effective in providing a high level of security and protection to prevent the theft of your vehicles, trailers, boats, & caravans whilst on your driveway. The automatic rising bollards usually installed in entrance of schools ,Banks government building park , it is becoming more and more popular now.

Product Details:

Control system	Integrated Electro-Hydrauli
Passing pressure	<=80-120 tons container trucks
Voltage	AC220V 50Hz Integrated
System Dynamic Power	350W Integrated
Rising Time	<=3-4S( can be customized)
Fall time	<=3-4S( can be customized)
Material	304 stainless steel
Rising height	600mm
Diameter	168mm,219mm,273mm( can be customized)
External housing size	4304301130mm/500500900mm
Thickness of bollard	6mm,8mm,10mm,12mm,15mm,30mm(optional)
Working temperature	-35 degree-75 degree( suitable)
Storage Environment	10 degree-65 degree, waterproof and moisture-proof
Solenoid Valve Voltage	24V
Remote control distance	Approx. 50m-100m
Waterproof	IP68, double sealed
Running noise	<=60db
Weight	120 KG approx.

Rating	K4/pas 68/iwa14:2013 (6.8 Ton Truck Impacted At 48 km)
Hydraulic Drive Unit	220 V / 42 V (Ac), 50 Hz
Unique Mechanism	In Built Tie Rod Mechanism
Protection Class	IP 68
Illumination	Red Led/ Reflective Bands
Duty Cycle	100%
Operating Temperature	-25c To +60c
Manual Lowering Operations	Available
Cylinder Diameter	219mm
Cylinder Length	900mm
Model No.	HB-AS1
Cylinder Material	High Tensile Carbon Steel
Rising Time (Emergency)	1~2sec or 3~4sec
Rising Lowering Time (Normal)	3 Sec.
